UAEBio Mix Pump Range
Roto Biomix pumps have been integrated into the process of renewable energy generation and are constantly upgraded and optimized to meet the customer’s demand. These pumps are used to mix and transfer solid bio waste and digestate liquid into the fermentation tank. Customized hopper available in round & rectangular shape up to 3 meter length.
|
m3/hr
|
7 | 10 | 14 | 18 | 26 | 37 |
|
GPM
|
31 | 44 | 62 | 80 | 115 | 163 |
Higher capacity & higher pressure pumps are also available on request.
Large Auger – Feed Screw
Designed for crushing & mixing of dry to wet media and feeding of the substrate. Option available in plasma nitrided coating.
Rectangular Hopper
Hopper option available with additional large inlet flange for substrate mixing.
Round Hopper
Designed to handle a high degree of dry solid content.
INSPECTION COVER
For easy access, quick inspection, and maintenance.
STONE CATCHER
Designed to trap large solid particles inside the hopper.
HEAVY DUTY BEARING HOUSING
Capable of taking high axial thrust and can be directly coupled with geared motor.
INBUILT FEED FLANGE
Left-handed & right-handed ports are included as standard for feeding digestate to ensure optimum homogenization.
CARDAN UNIVERSAL JOINT
Universal joint with sleeve protector & flight wing to avoid any solid build-up.
SMARTER SHAFT SEALING
Cartridge dual mechanical seal with oil lubrication plan for longer life.
